19" Monitor Sunlight Readable TFT-LCD, Projected Capacitive Touch (PCAP), IP65 Front, VGA, DVI-D, DisplayPort, 9~48VDC

  • Pack

19" TFT SXGA
5:4 LCD with PCAP Touch
50,000 HRS LED Backlight Life
1x VGA, 1X DVI-D, 1x DisplayPort
Resolution Up to 1280 x 1024 (SXGA)
Up to 1600 Nits Brightness
Designed with Aluminum Die-Cast Frame
IP65 Compatible Front Panel
Convertible Display System (CDS) Supported
9~48VDC via 3-pin Terminal Block

This pack contains

I/O Module for Industrial display
x 1
19" High Brightness Modular monitor
x 1
MON19-SOL-CDS
12,451.00 DKK
Tax excluded
Quantity
On the way in

  • Download PDF
  • file_download Downloads
  • live_help Ask a question

MON19-CDS is 19" LCD display module with projected capacitive touch. It offers resolution up to 1280x1024 (SXGA) and 1600 nits brightness. MON19-CDS features flat surface and IP65 dust/waterproof front panel. In addition, designed with aluminum die-cast front frame, it is rugged and reliable for industrial environment. With support for Convertible Display System (CDS) technology, MON19-CDS allows you to configure, upgrade and maintain your Convertible Display System easily.

Driftstemperatur
-20°C to 70°C
Forsyning
9~48VDC via 3-pin Terminal Block
IP-Tæthed
IP65 Compliant Front Panel
Lysstyrke
up to 1,600 nits
Skærm
19” TFT-LCD
