Weighing amplifier (DC supply)

For 24 VDC supply

SGA/D
4,348.00 DKK
Tax excluded
Quantity
On the way in

  • Download PDF
  • file_download Downloads
  • live_help Ask a question

Weighing amplifier for strain gauge cells.

For use on load cells together with standard A/D cards.

Converts the measurement signal from strain gauges (load cells, pressure transducers, etc.) into an output signal of 4 – 20 mA and 5 V / 10 V

The SGA/D can be used to advantage with any of the voltage meters or A/D cards shown in this chapter.

The mounting box is IP65 sealed and suitable for mounting close to load cells.

For supply with 24 VDC.

Forsyning
Til forsyning med 24 VDC
Indgang
Justerbar følsomhed til strain gauge transducere fra 0,1 til 30 mV/v
Udgange
±10 V, ±5 V, 0 - 10 V, 0 - 5 V samt 4 - 20 ell. 0 - 20 mA
