RS485 repeater, 1200m, 300 - 115.2kBit/s, double opto-isolated, 10 - 30VDC, -25 - +75°C

Repeater and splitter of an RS485 signal
Up to 3 branches, as a star connection
It is very IMPORTANT to avoid bus reflections.
Use M485-REP3-I if the RS485 bus is to be split out for DIN assembly

Repeater and splits an RS485 signal into 4 branches
RS485 master on input polls RS485 slaves with ID
Only asked RS485 slave responds only to master
No RS485 slave can poll the RS485 bus
2-wire RS485 - semi-duplex
Extend the star bus with more M485-REP4-I
Supply: 10 - +30VDC
Temp: -25 - +75°C
For DIN-Rail mounting

Optoisolerated RS422 / RS485 Repeater
3000vdc Glavanic isolation
2 threads RS485 is half duplex (switch-talk)
4 threads RS485 / RS422 A full duplex (both ways at the same time)
Translator from RS422 (4-wire) for RS485 (2-wire), semiduplex
automatic directional change and baud rate.

Isoleret RS485 repeater til DIN skinne
