GSM / LTE alarm - 4G
Configuration via USB (Windows program) or SMS
2 x digital inputs with "dry contact" or "logic level" mode
2 x analog input from 0 to 60VDC, 10 bits
2 x relay output with NO / NC switches
1-Wire interface for 4 Teracom temperature and humidity sensors
Input can be navigated with alarm text etc.
SMS alarm - up to 5 numbers
Email alarm - up to 5 email recipients, SMTP with TLS support
1 relay can be activated with calls from up to 100 telephone numbers
Push mode - XML data is sent via HTTP Post to a remote server. Server response may include relay setup.
MQTT 3.1.1 support
Firmware update "on air"
Supply voltage: 8 - 32VDC, 2Watt - additional PSU
Dimensions: 109 x 65 x 32 mm
Weight: 152g
TCG120 is an I/O controller with GSM remote monitoring and control via mobile network. It has two digital inputs, two analog inputs. Its 1-Wire interface supports up to 4 Teracom humidity and temperature sensors. It's two relays have normally open and normally closed contacts.
The relays can be activated either externally (via SMS or HTTP response from external server) or locally - from the status of the monitored parameter. Only one parameter can control the relay at the same time, but for each parameter an e-mail or SMS can be sent to the alarm administrator.
TCG120 can initiate a connection (HTTP mail) to the remote dedicated servers - XML file, with current values for monitored parameters.
HTTP mail can be sent periodically or upon preset alarm conditions. The server can then respond with relay setup (see the manual under "Downloads"). This is very useful in client-server systems for GSM-GPRS remote monitoring and control
The controller can be used as a stand-alone unit or as part of data monitoring systems (SCADA).
Mains adapter - switch mode type
110-240 VAC to 12VDC/1.5A
DC plug: 5.5/2.1 mm
1 meter cable
Switch mode type
110-240 VAC for & nbsp; 12VDC / 3A
DC connector: 5.5 / 2.1 mm
USB 2.0 kabel beregnet til mini USB standard, 28 AWG.
Forhandles i forskellige længder.
Multi-band 4G LTE Cat.1 controller, logger and alarm
Setup via USB, SMS and HTTP API
USB setup - use USB cable with Mini B male
2 digital "dry contacts". High on contact
2 analog inputs, 0 - 10VDC or 4-20mA input (10bit)
4 relay outputs, COM, NO and NC
1-Wire input for up to 8 Teracom sensors
1 x RS485 for max. 8 MODBUS RTU sensors
Data logger with 70,000 logs
Upload data to HTTP/HTTPS Post in XML/JSON
SMS alarm and Email alarm to 5 recipients
Push mode – XML data is sent via HTTP Post to a remote server. Responses from server may contain relay setup.
10 to 28VDC, 370mA @ 12VDC - additional PSU
Dimensions: 158 x 119 x 34 mm
Weight: 470g
Temperature: -20 - +55°C
Get your free license key from Teracom
DAQ software for Teracom Ethernet-based measuring devices
User-friendly WEB interface for easy configuration and control
Flexible user access and management
Distributed monitoring units in "client" fashion
Alarm notification
Activity log
Graphics and data display with large visualization
Easy access to raw data, tables, export in CSV format (comma separated)
Database management
Send command to check in "server" and "client" mode
command status log
1-wire communications - several sensors can be connected to the same unit
± 3.0% relative humidity accuracy
± 0.4% relative temperature accuracy
12 bit resolution for humidity measurement
14 bit resolution for temperature measurement
Calibrated digital output
Eksellent long-term stability
Each sensor has its own unique 64-bit serial number
Open board til smart temperatur- eller fugt måling and styring
Password beskyttet Web baseret konfiguration og kontrol
1 x digital input med “dry contact” og “logic level” mode
1 x analog input fra 0 til 60VDC
1 relæ output med NO/NC kontakter
1-Wire input til 1 temperature eller fugtmåler
SNMP v.1 support
SNMP traps ved alarm
E-mail udsendelse ved alarm
SMTP med godkendelse (SSL/TLS er ikke supporteret)
HTTP og XML API kommandoer
Remote FTP firmware update.
