Internal USB to RS232 converter card with 5V on DB9
Two 16550 High performance UART (RS232) serial channels
Occupies one PCI or PCIe bus slot
Low Profile PCI Form Factor
Includes Low Profile PCI & Regular size PCI two brackets
Both USB A type and USB pin header connector on board to host connection
One RS232 DB9M and one RS232 10pin RJ45 serial ports on board
Includes one 10pin RJ45 – DB9M Bridge cable for 2nd DB9M port
5VDC Power output from each DB9M Port for POS device use application
2 Jumpers Individually enable / disable 5VDC output for each DM9M Port
On Board Molex mini 4Pin Power connector for sufficient DB9M 5V bus power from PC power supply
Supports 32bit/64bit Windows 7, Vista, XP, 2000, ME, 98SE
178.00 kr
Ekskl. moms
Quantity
Physically in stock
Product number CNV-USB-RS232INT
Ask a question
close
Specifications
Drivere | Windows 2000, XP, 2003, Vista, Win7 og Win8 |
---|---|
Høj/lav bagplade | Begge bagplader medfølger |
I/O | Plug & Play |
Maks. hastighed | 230 Kbit/sekund |
Porte | 2 x RS232 |
Stik | 1 x DB9 han og 1 x RJ45 hun (RJ45 til DB9 kabel medfølger) |
Strømforsyning | Forsynes af 4-pins Molex stik |
UART | 16550 |
USB | Tilsluttes enten USB A hunstik eller pins på kortet (medfølgende kabel forbindes til 4 pins på kortet og 4 USB-pins på bundkortet) |
With CNV-USB2RS232INT, newer PCs can get 2 x RS232 ports without having external boxes connected. The card is connected to an internal USB connector (USB cable not included) or directly to the motherboard using the supplied cable. 5 VDC can be supplied from the serial port for e.g. POS equipment. The voltage is activated / deactivated with jumpers on the card.
