7 x inputs for temperature sensors (differential), Pt100, Pt1000, Ni120, CU100, CU1000, 2 x RJ45 LAN, MODBUS, PoE
Built-in Web server
Web HMI
Modbus TCP and Modbus UDP protocols
Good communication security
2 x RJ45 port Ethernet - Daisy chain to the next module
Dual Watchdog
Operating Temperature Range: -25 to + 75 ° C
I / O Pair-connection input is mirrored in the other's output
7 x RTD Interface: Pt100, Pt1000, Ni120, CU100, CU1000
Differentialindgange to the temperature sensor 2 and 3- wire
16bit resolution
Power supply: PoE or 10 - 30VDC / 2.5watt
PoE is NOT passed on to the next module - only data.
