1 port serial server RS232 / RS422 / RS485. Serial Device Server RJ45, DB9, 9 - 30VDC
External COM port over Ethernet and Internet
RS232/422/485
Baud rate: 1200 - 230.4kbps (2-wire)
Max. baud rate at 4-wire RS485 up to 921.6kbps
Atop SE5201-DB Serial Device Server
10/100Mbit Ethernet.
Serial port via DB9 male connector
Supports TCP Server/Client, UDP, Virtual COM and Tunneling modes
Power is supplied from 9 - 30VDC or 5VDC (power jack)
Power supply not included
DIN kit (option)
Dimensions: 65 x 78 x 28mm (without wall bracket)
Dimensions: 88.5 x 84 x 27.8mm (with wall bracket and DB9 port)
