16 x Voltage inputs, up to +/- 10V, 16bit, 2 analog outputs +/- 10V, 16bit, 16 DI / DO, LAN

Measurement module with 16 analog inputs (16 bit, ± 10V, ± 5V, ± 2V, ± 1V)
Sample speed 250kHz
2 analog outputs (16bit, ± 10V)
Galvanically insulated to LAN
16 Digital Inputs - TTL / CMOS
16 Digital & Nbsp; Outputs - TTL / CMOS
3 Counters (32 bit, max 16 MHz) for Pulse, Increment Decoder or Pulse Time Measurement
TCP/IP Ethernet Power supply from PoE or externally with 12-40VDC - Real-time synchronized
Windows, MAC, Linux drivers
Supplied with programming examples in VB, C ++ Delphi, .NET
Can be used with NextView, LabVIEW, and Profilab Graphic Programming Software
30-day free trial with NextView 4

AD16S2-ETH
DKK9,592.00
Tax excluded
Quantity
On the way in

  • Download PDF
  • file_download Downloads
  • live_help Ask a question

Network Connection Voltage Meter.
16 analog voltage inputs with Ethernet & nbsp; connectivity. Up to 250kHz.
AD16S2-ETH can be connected to local and / or internet. It provides flexibility regarding distance and location of PC.

Netværk
10/100 Mbit RJ45 stik
Driftstemperatur
0 – 50 °C
Udgange
2 stk. ±10 V ”Single ended” analog
Indgange
16 stk.”Single ended” analog
Stik
Analog DB37 hunstik, digitale DB37 hunstik
Andet
16 digitale indgange og 16 digitale udgange TTL
Opløsning
16 bit på ind- og udgange
Forsyning
9 - 30 VDC Maks. 5 W
Nøjagtighed
±0,1 %
